5876-335 - Headlight Assembly

Introducing the all-new Oculus(tm) Bi-LED Headlamp system by ORACLE Lighting. Now available in a ColorSHIFT(tm) RGB+W Color-Changing version! Featuring advanced LED projection with 4,800 Lumens of high-quality illumination for enhanced driver visibility in all weather conditions. The LED light source has lower power demands compared to the factory lamps while providing more light output. ColorSHIFT(tm) Oculus(tm) Headlights feature 3-Tiered RGB features in the lamps: Outer Halo Ring (RGB+W) Inner Halo Ring (RGB) Projector Demon Eye (RGB) Each LED feature has a separate cable output and can be connected together so all 3 create the same color or set up as 3 separate Channels or zones depending on the user preference and the ColorSHIFT(tm) controller selected. Check out our Y-Splitter Adapters for the easiest control using our BC1 ColorSHIFT(tm) Controller Please note that these features are intended for off-road show use only and are not compliant for street use. The Pure-White DRL has its own wiring harness (same as the original Oculus) that connects to the fuse box with an add-a-circuit for easy and safe integration. The DRL will come on when the engine is running or can be connected to a switch (including the factory Aux switches) for additional user control.

• Remote mounted heat sinks and an internal cooling fan work in conjunction to insure proper temperature control and longevity of the LEDs

Attributes:

• Brand Name: Oracle Lighting
• GTIN: 00810030396970
• Adaptive Headlight: No
• Adaptive High Beam: No
• Add-On: N/A
• Adjusting Screw Included: Yes
• Amperage Rating: 3
• Automatic Leveling Included: No
• Automatic On/Off Light: Yes
• Average Rated Life: 60000
• Background Color: Black
• Ballast Included: Yes
• Beam Type: High Beam Low Beam
• Bezel Color: Black
• Brightness: 5200
• Bulb Color: 6,000K
• Bulb Quantity: 2
• Bulb Technology: Bi-LED
• Bulb Type: H4/H13
• Bulbs Included: Yes
• Certification: DOT SAE HL VOR 19
• Color: ColorSHIFT - w/BC1 Controller
• Color Temp: 5500K
• DOT Approved: Yes
• Daytime Running Light Included: Yes
• Details: Precision LED lighting projector for optimum light distribution and beam angle. Installs using original mounting hardware and headlight wiring is Plug & Play into the factory connector without additional relays or harnesses. Halo DRL features over 200 bright white LEDs for a vivid lighting impact.
• Emergency Warning Lights Included: No
• Headlight Light Projection Technology: Projector
• Headlight Type: Assembly
• High Beam Wattage: 36
• Housing Color: Black
• Housing Material: ABS
• LED Accent Included: Yes
• Lens Color: Clear
• Lens Material: PC (Polycarbonate)
• Low Beam Bulb Technology: Bi-LED
• Mounting Hardware Included: No
• Night Vision Included: No
• Patent: Multi-National Patented Design
• Purpose: These all-new headlamps provide enhanced driver visibility with increased and focused LED light output. Complete headlight replacement, better light focus than a simple bulb upgrade. Uses original factory beam angle adjust-ability for proper light focus on lifted Jeeps.
• Secondary Amperage Rating: 3
• Street Legal: Yes
• Terminal Type: Blade
• Total Raw Lumens: 5,200LM
• Turn Signal Included: No
• Voltage: 12
• Warranty Period: 2 Years
• Wattage: 36W Each

Extended Information:

• Country of Origin: US
• Emissions : Emissions Compliance Exempt
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 8 x 8 x 17 inches
• Weight: 7 POUNDS
